Soft LED Screen Make it Ultra-Flexible for Cylinder, Cube, Convex & Concave Applications

Short Description:

LSX series LED screen is whats called flexible LED screen.It is made up of LED pixels pitched on a pliable material like rubber. It is insulated with a flexible material on sides to prevent the LED circuit from getting damaged, which makes flexible LED screens super resilient.

Flexible LED panel is also called soft LED screen or soft panel, the obvious feature is that the panel is very soft and flexible. Because its ultra-flexible, panels are available for customized design, such like rolling, bending, twisting and swing based on customer’s demands.

Send email to us

Product Detail

Technical Parameters

Case Appreciation

Download

Product Tags

Product Features

★ Black LED, high contrast ratio,High refresh rate, no ghosting

★ Silicone frame and customized PCB with bigger bended angle

★ Perfect alignment no gaps & great flatness

★ Waterproof IP68

★ Anti fire / corrosion material

★ Diameter ≥500mm

LSX Series LED Screen Is Whats Called Flexible LED Screen

Its also ultra-thin LED display ,which adopt special material and advanced technology, super thin and light, weight of each module is just 85g.

Easy assemble feature make it easy installation, strong magnet, available for front service.

Also its non-cabinet,which reduce weight of LED display and cost and could be any shape design as customer required.

Flexible LED Display

Flexible LED display are available in varying sizes,Thus you can get either a small unit or an out-sized unit to meet your needs. Primarily, we know that in-store signage and publications are using such displays. The wall has plenty of LEDs, although a few panels and frames are on the stage.

These LED Panels Are Mainly Used For Making Flexible LED Display.

These LED panels are mainly used for making flexible LED display, creative LED display,customized LED display and irregular shape LED display such as fan-shaped, cylinder, cube, convex & concave applications.

For indoor applications, flexible LED screen is ideal option , like at supermarket, airport, hotel lobby ,etc. A creative, flexible LED display is also the right one to choose if you need to make the LED installation screen round and curved or indoor fixed. Without any doubt, It is needed anywhere.

Video

Previous: Creative Sphere LED Screen Stands Out with 360 Degree Viewing Angle

Next: Innovative Visual Solution Transparent LED Panel Overshadows Traditional LCD in Brightness

Environment	INDOOR								OUTDOOR
Product Name	LSX1.2	LSX1.5	LSX1.667	LSX1.8	LSX2	LSX2.5	LSX3		LSXO3.8	LSXO6.67	LSXO10
Pixel Pitch(mm)	1.25mm	1.579mm	1.667mm	1.875mm	2mm	2.5mm	3mm		3.81mm	6.67mm	10mm
LED Type	SMD1010	SMD1212	SMD1010	SMD 1515	SMD 1515	SMD 2121	SMD 2121		SMD 1921	SMD3535	SMD3535
Pixel Density (pixels/m2)	640000	401111	360000	284,444	250,000	160,000	111,111		68,644	22,478	10,000
Cabinet Size ( W x H x D)	480*480								304.8*304.8	320*320	320*320
Modules/Cabinet (W x H)	2*4								1*1	1*1	1*1
Module Resolution	192*100	152*76	144*72	134*67	120*60	96*48	80*40		80*80	48*48	32*32
Module Size (W x H)	240*120	240*120	240*120	240*120	240*120	240*120	240*120		304.8*304.8	320*320	320*320
Power Consumption Maximum (W/m2)	750	750	750	750	600	600	600		900	900	900
Power Consumption Typical (W/m2)	250	250	250	250	200	200	200		300	300	300
Line Voltage	AC110-240V ,50-60HZ
Cabinet Material	Iron
Brightness Max, Calibration On (cd/sq))	≥600	≥600	≥600	≥600	≥600	≥600	≥600		≥5000	≥5000	≥5500
LED Refresh Rate	3840	3840	3840	3840	1920	1920	1920		3840	3840	3840
Color Temperature Adjust (k)	2000~9000
Viewing Angle (Horizontal/Vertical°)	120°/ 120°	120°/ 120°	120°/ 120°	120°/ 120°	120°/ 120°	120°/ 120°	120°/ 120°		120°/ 120°	120°/ 120°	120°/ 120°
Frame Rate	50/60HZ
Gray Scale Processing	14+2 bit
Service Access	front
LED Lifetime, Typical	100,000H
Runtime Duty Cycle (Hours/Day)	24/7
Storage Temperature/ Humidity	-20℃~45℃							20℃~60℃
(degrees F/C) 10-85% relative humidity,
non-condensing
Opertating Temperature/ Humidity	-20℃~45℃							20℃~60℃
(degrees F/C) 10-85% relative humidity,
non-condensing
IP Rating (F/R)	IP20/IP20	IP20/IP20	IP20/IP20	IP20/IP20	IP20/IP20	IP20/IP20	IP20/IP20		IP68/IP65	IP68/IP65	IP68/IP65
Drive	1/48 scan	1/38 scan	1/36 scan	1/32 scan	1/30 scan	1/24 Scan	1/24 Scan		1/10 Scan	1/6 Scan	1/2 Scan
